Ntsia Hlau Loj Ntau Qhov Siab Siab Sensor

Ntsia hlau loj ntau nro siab sensor
Lub ntim me|siab precision|rub thiab nias dual siv.
Rub thiab siab tuaj yeem siv tau, kev ntsuas yooj yim dua.
High precision strain gauge: Kev ruaj ntseg mus sij hawm ntev, siab rhiab heev, kev pab lub neej ntev.

Xa kev nug

Hauj lwm lawm

Ntsia hlau loj ntau nro siab sensor

Micro sensor, qis qhov siab, me me deformation, loj ntau, stainless hlau seem, rub thiab siab ob-txoj kev, feem ntau yog siv nyob rau hauv automotive nias, tsis siv neeg sib dhos, 3C khoom kuaj, tshiab zog khoom sib dhos, kev kuaj mob, neeg hlau teb, pwm los ua ke thiab lwm yam kev lag luam automation teb.

Technical specification
ntau	0.1/0.2/0.3/0.5/1/2/3/5T
Ua ke yuam kev	Tsawg dua lossis sib npaug ±0.2%	rhiab heev kub nyhuv	± 0.05%FS/10 degree
Kab tsis sib deev	0.2%	Zero kub nyhuv	± 0.05%FS/10 degree
rhiab heev	1.5 ± 10% mV / V	Kub them nyiaj ntau yam	-10 ~ 60 degree
nkag	± 0.05%FS/30min	Kev pab kub ntau yam	-20 ~ 80 degree
Zero tso zis	±2.0%F.S	Excitation voltage	5~15V
Input impedance	700±10Ω	Safe overload ntau yam	150%F.S
Cov zis impedance	700±10Ω	Limit overload range	200%F.S
Rwb thaiv tsev tsis kam	Ntau tshaj lossis sib npaug rau 5000MΩ / 100V DC	Cable specification	φ4mm × 3m
Chav kawm ntawm kev tiv thaiv	IP66
